The Excelsys Xsolo platform comes with a host of features including: variable speed fan, 12V/300mA isolated bias supply, remote ON/OFF, output voltage control and parallel operation for higher power applications. Nominal output voltages are 24V, 36V and 48V with wide adjustment ranges and user defined set-points.
The Excelsys Xsolo now meets CE101 and CE102 conducted emission standards by combining with the ASTRODYNE-LCR F19374 High Performance Single Stage Power Line Filter. The ASTRODYNE-LCR F19374 Filter is designed to bring the complete Excelsys XF Modular Power Supply Platform and the Excelsys Xsolo Platform to compliance with MIL-STD 461F, CE101 and CE102 conducted emissions under various loads.
Excelsys Xsolo Modular Power Supply FEATURES：
1、Single output: 24V, 36V or 48V
2、Ultra high efficiency, >92%
3、Dual Safety Approvals:
4、UL/EN60950 2nd edition & IEC60601-1-2 4th edition (EMC)
5、Low profile: 1U height (40mm)
6、Convection Cooled 500W
7、Fan Cooled 1000W (variable speed fan)
8、12V/300mA bias standby voltage provided
9、Remote ON/OFF Signal
10、Power Good Signal
11、MIL810G
12、2 MOPP
13、CE101 & CE102 Compliant
14、Suitable for Type B and BF rated applications
15、SEMI F47 Compliant
16、Optional I2C PMBus™Communications
17、Optional OR-ing Function
18、5 Year Warranty
Excelsys Xsolo Modular Power Supply APPLICATIONS INCLUDE:
1、Medical
2、Industrial
3、Test & Measurement
4、Hi Rel COTS
5、Communications
