Amotech AIES12U020R2 ESD SUPPRESSOR

Source: Time:2017-05-24 12:13:54 views:

        AIES Series is specially designed to protect sensitive electronics from the threat of the electrostatic discharge (ESD). The Amotech AIES12U020R2  ESD SUPPRESSOR reacts almost instantly to the transient voltage and effectively clamps it to the low voltage for the duration of the ESD transient. The Amotech AIES12U020R2  ESD SUPPRESSOR uses voltage dependant variable materials that inherently produce low capacitance and very low leakage current. Thus the device is virtually invisible to the circuit during normal operational mode. It is especially transparent to the high-speed digital circuits due to the high off-state impedance and low capacitance. Signals are not distorted or disrupted as shown by extensive testing. Using the Amotech AIES12U020R2  ESD protection, devices maintain signal integrity of high-speed data signals while protecting the circuit from ESD. The nature of the material creates a bi-directional part, which means that only one device per surge path is required to provide complete ESD protection regardless of the surge polarity.
AIES12U020R2
The Amotech AIES12U020R2  ESD SUPPRESSOR Features:
• Exceeds testing requirements outlined in IEC 61000-4-2
• Ultra low capacitance (0.15pF typ.)
• Very low leakage current
• Fast response time
• Bi-directional

The Amotech AIES12U020R2  ESD SUPPRESSOR Main application field:
1、ESD protection of SAW filter & diode switch in RF circuit

2、 ESD protection of USB 2.0 (high speed and full speed) circu


The Amotech AIES12U020R2  Electrical characteristics:

 Characteristic  Value
 Rated Voltage (Vdc)  12Vdc typ
 Clamping Voltage (VC_ESD)  35typ, 50max
 Capacitance (Cp, @ 1MHz)  0.15pF typ, 0.3pF max.
 Leakage Current (IL, @ 12Vdc)  1 uA max.
 ESD Capability
 IEC61000-4-2 Direct Discharge
 IEC61000-4-2 Air Discharge
 8kV typ.
 15kV typ.
 ESD Pulse Withstand  >1,000 typ.
 Operating Temperature  -40°C to +85°C



AIES12U020R2 《AIES12U020R2 》download
