The AE HVA Series Features：
* Output voltage 0 ~ 10kV
Bipolar: 0V to ± 5kV, unipolar: 0V to 10kV
* Precision high-voltage amplifier
* DC to 1kHz output
* Operates in DC, reversible and amplifier modes
* 25-125ppm voltage ripple
* 15ppm / ° C temperature coefficient
| Bipolar Model | Output Voltage | Output Power | Ripple(pk-pk) |
| 1HVA24-BP1-F-15ppm | 0V to ±1kV | 250uA | <125ppm |
| 2HVA24-BP1-F-15ppm | 0V to ±2kV | 250uA | <125ppm |
| 4HVA24-BP1-F-15ppm | 0V to ±4kV | 250uA | <125ppm |
| 5HVA24-BP1-F-15ppm | 0V to ±5kV | 200uA | <75ppm |
| Unipolar Model Examples | Output Voltage | Output Power | Ripple(pk-pk) |
| 1HVA24-P1-F-15ppm | 0V to +1kV | 250uA | 125ppm |
| 2HVA24-N1-F-15ppm | 0V to -2kV | 250uA | 125ppm |
| 4HVA24-P1-F-15ppm | 0V to +4kV | 250uA | 125ppm |
| 5HVA24-N1-F-15ppm | 0V to -5kV | 200uA | 75ppm |
| 6HVA24-P1-F-15ppm | 0V to +6kV | 167uA | 75ppm |
| 10HVA24-N1-F-15ppm | 0V to -10kV | 100uA | 25ppm |
