ACF series is multi-layer chip Common Mode Filter for high speed differential transmission line.The ACFE1A2G900E shows excellent noise reduction without signal loss by high coupled Inductor pair.
The Amotech ACFE1A2G900E Features：
1、 Excellent noise reduction without signal loss
2、Built-in two ESD suppression devices each line
3、Low profile (thickness = 0.6mm)
4、Ceramic multilayer type SMD component
5、RoHS compliance
The Amotech ACFE1A2G900E Applications：
1、High speed differential transmission lines at electronic devices (ex. MHL, HDMI, etc.)
The Amotech ACFE1A2G900E Caution：
1) Storage environment : -5~40℃ temperature, 20~70% humidity (MSL Level 1)
2) Do not use in high temperature/high humidity and a corrosive atmosphere like sulfide, chloride gas which could damage the solderability.
3) Do not expose to mechanical shock to avoid crack.
1、 Excellent noise reduction without signal loss
2、Built-in two ESD suppression devices each line
3、Low profile (thickness = 0.6mm)
4、Ceramic multilayer type SMD component
5、RoHS compliance
The Amotech ACFE1A2G900E Applications：
1、High speed differential transmission lines at electronic devices (ex. MHL, HDMI, etc.)
2、LCD/PDP TV, DSC, DVC, DVD player, notebook, PC, portable audio player, mobile phones, etc.
The Amotech ACFE1A2G900E Electrical characteristics：
| Parameter |
Common Mode Impedance @ 100 MHz |
DC Resistance |
Capacitance @ 1MHz |
Rated Voltage |
Rated Current |
Insulation Resistance |
Leakage Current @ 5Vdc |
| Symbol | ZCM | RDC | CP | VDC | IDC | IR | IL |
| Units | Ω | Ω | pF | V (DC) | mA (DC) | MΩ | μA |
| Value | 90 ± 25% | Max. 4.0 | Max. 1.2 | 10 | 100 | Min. 10 | Max. 1 |
The Amotech ACFE1A2G900E Caution：
1) Storage environment : -5~40℃ temperature, 20~70% humidity (MSL Level 1)
2) Do not use in high temperature/high humidity and a corrosive atmosphere like sulfide, chloride gas which could damage the solderability.
3) Do not expose to mechanical shock to avoid crack.
4) Use chips within 6 months. If over 6 months, check solderability before use.
《ACFE1A2G900E》download
