Silver Wing and DAMAI committed to the development of WI-FI module to reach a co-operation.LinkPlay Wi-Fi Audio module A28, is our second generation smart audio modules developed to be used inwireless speaker, wireless docking station, Wi-Fi base station, home automation and smart toy. LinkPlay Wi-Fi Audio module A28 supports 802.11b/g/n standard with up to 300Mbps bandwidth. It could work at AP, AP client or station modes. It is fully compatible with Apple AirPlay and digital living network alliance (DLNA) streaming standards. LinkPlay Wi-Fi Audio module A28 supports Hi-Fi audio up to 192Khz, 24-bit with most popular audio formats. It supports multi-room and multi-channel audio streaming with perfect synchronization.With this module, you can play the music on your speaker wirelessly from iPhone, iPad , iPod touch, Android devices or PC.
1、Support 2.4GHz 802.11 b/g/n with highly optimized Wi-Fi performance
2、Support 10/100Mbps Ethernet
3、Support Internet audio streaming via Apple AirPlay or DLNA
4、Support Spotify, Pandora, iHeartRadio, Tidal, Tune in and many more ...
5、Support TCP/IP/UDP/HTTP/UPNP protocol,Support play-list with M3U, M3U8, WPL, ASX, PLS formats
6、Support MP3/WMA/AAC/AAC+/ALAC/FLAC/APE/WAV etc. audio formats7、Support STA/AP/AP Client mode, Support Ethernet, UART and USB2.0 interfaces
8、Support digital audio input and output via I2S interface
9、Built-in web server to easily configure the module
10、Support remote control of module via WLAN
11、Support online firmware upgrade
12、Support module configuration via iOS or Android APP
13、Support Wi-Fi UART pass-through or self-defined MCU/UART interface
14、Support multi-room audio (a.k.a, party mode) and multi-channel audio with perfect time synchronization
15、among speakers
16、Support most popular streaming services around the worldProvide iOS, Android and PC SDK and applications to work with the module
LinkPlay Wi-Fi audio module A28 technical parameters:
Main chip: MT7628AN
Frequency: 580MHz
Memory: 64MB (DDR2)
Wireless standard: 802.b / g / n
Wireless Rate (Max.): 300Mbps
Working frequency band: 2.4G
Number of antennas: 2T2R
Antenna Interface: External I-PEX
Operating current (@ 5V): 130mA ~ 320mA
Working temperature: -5 ℃ ~ 40 ℃
Physical size: 28.5mm x 42.0mm
LINKPLAY WI-FI MODULE APP INTERFACE SUPPORT: My Music, TTpod, Pandora, Tunein, MULTIROOM, iHeartRadio.
